MAKERELE Aluminum Heat Sink for Solid State Relay Modules
MAKERELE white aluminum heat sink for compatible single-phase solid state relay modules. The finned body increases the available surface area for heat transfer in a correctly designed panel installation.
Key features
- Aluminum construction: finned heat sink body with a flat relay mounting surface.
- Source-listed size: approximately 80 × 50 × 50 mm; use the dimension drawing for mounting reference.
- Relay reference range: source-listed for compatible single-phase SSR modules from 25 A through 120 A.
- One-piece pack: each order option contains one heat sink.
- Accessory boundary: relay, thermal compound and mounting screws are not included.
Specification reference
| Material | Aluminum |
|---|---|
| Color | White / natural aluminum appearance |
| Approximate size | 80 × 50 × 50 mm |
| Source-listed relay range | 25 A to 120 A single-phase SSR |
| Pack | 1 heat sink |
| SKU | MK-HS855-W |
Installation notes
- Confirm relay footprint, mounting-hole spacing and required thermal performance before ordering.
- Apply suitable thermal interface material evenly between the relay base and heat sink according to the component manufacturer's instructions.
- Secure the relay with appropriate hardware and maintain enclosure ventilation and clearance.
- Electrical and thermal design should be completed by qualified personnel.
FAQ
Does this listing include a relay?
No. The listing is for one heat sink only.
Can every 25 A–120 A relay use the same heat sink?
The range is source-listed as a compatibility reference, but the project designer must confirm footprint, mounting and heat dissipation for the exact relay and load.
