MAKERELE 3.1 in Square Spring-Loaded Speaker Terminal Cups
3.1 in Square Spring-Loaded Speaker Terminal Cups
Add a two-terminal connection point to a compatible passive speaker or subwoofer enclosure. This MAKERELE model uses a square nominal 3.1 in mounting face with color-coded spring-loaded terminals and is offered in 1-, 2- and 4-piece packages.
Key Features
- Square mounting profile: source dimension image shows an approximately 80 mm / 3.14 in face.
- Spring-loaded terminals: color-coded two-way connection for compatible bare speaker wire.
- Cup depth reference: source dimension image shows an approximately 67 mm / 2.63 in body depth.
- Mounting hardware: supplied with the gaskets and screws shown for the selected pack quantity.
- Exact pack choices: separate 1-, 2- and 4-pack SKUs; 2- and 4-pack source images are identified by count.
Pack and SKU Guide
| Pack | SKU | Package reference |
|---|---|---|
| 1-Pack | 80SpeakerBox-FAN-4S-1 | 1 square spring-loaded terminal cup with hardware |
| 2-Pack | 80SpeakerBox-FAN-4S-2 | 2 square spring-loaded terminal cups with hardware |
| 4-Pack | 80SpeakerBox-FAN-4S-4 | 4 square spring-loaded terminal cups with hardware |
Fit and Installation
Measure the enclosure cutout, mounting area and hole pattern before ordering; the nominal 3.1 in description does not guarantee drop-in compatibility with every cabinet. Observe polarity, isolate the amplifier before wiring and avoid overtightening the plastic frame.
FAQ
Is this the round terminal cup?
No. This page covers the square spring-loaded model.
Does pack quantity change the terminal design?
No. It changes only the number of cups and matching hardware supplied.
| Pack Quantity |
1-Pack, 2-Pack, 4-Pack |
|---|
